CNC Base Plate

CNC Base Plate for Automated Equipment — Precision Aluminum Mounting Solution with ±0.01mm Accuracy

Wuxi Kaihan Technology delivers high-precision structural mounting components tailored for industrial automation scenarios. Our CNC Base Plate for Automated Equipment is professionally manufactured from premium 6061-T6 aluminum alloy via full three-axis integral CNC milling. This precision base plate achieves ultra-tight machining tolerances, with mounting hole accuracy up to ±0.01mm and datum flatness controlled within 0.05mm.

Adopting an integrated U-shaped structural design and equipped with multi-directional threaded holes, the product undergoes fine sandblasting and natural anodizing treatment, with surface roughness stably maintained at Ra1.6–Ra3.2. Backed by 15 years of precision machining experience, 22 independent technical patents and standardized ISO 9001 quality management system, our CNC Base Plate for Automated Equipment has been widely supplied to global clients in industrial automation, robotic equipment and vision inspection industries, delivering stable and reliable structural support solutions.

Material & Construction: Built for Industrial Reliability

We select 6061-T6 aluminum alloy as the core raw material for automated equipment base plates, which perfectly balances lightweight performance and structural rigidity. With a low density of only 2.7 g/cm³, this material effectively reduces the overall load of moving equipment modules without sacrificing structural stability.

Boasting excellent mechanical properties, the alloy features outstanding bending resistance and deformation resistance. It can maintain stable structural performance even under long-term high-speed reciprocating operation, far exceeding the reliability of traditional cast and welded structural parts in dynamic automation working environments.

The whole-piece one-time milling process eliminates all welding seams and assembly joints. Internal material stress is fully released during precision machining, effectively avoiding warping, deformation and loose assembly problems caused by long-term operational load, ensuring long-term dimensional stability of the base plate.

Surface Treatment: Durable, Corrosion-Resistant Finish

All finished base plates adopt dual-process surface treatment of overall sandblasting plus natural anodizing. This craft forms a uniform and dense protective layer on the aluminum surface, significantly improving the product’s wear resistance and scratch resistance.

The anodized film is tightly bonded with the aluminum substrate, with no peeling or chipping during daily assembly and workshop operation. It can effectively resist erosion from workshop humidity, oil mist and cutting fluid, maintaining complete surface integrity and avoiding oxidation and rust in harsh industrial environments.

To meet diverse application demands, we provide optional upgraded processes: hard anodizing for scenarios requiring higher surface hardness, and black anodizing for clients with customized appearance and equipment identification requirements.

Technical Specifications

Structural Design: Modular and Versatile

The unique U-shaped slotted integrated structure is the core advantage of our base plate design. It supports multi-angle mounting and operation, greatly simplifying the assembly and integration process of complex automated equipment.

Standard threaded holes and through fixing holes are evenly distributed on the top, side and end faces of the base plate. The multi-directional hole layout enables direct installation of cylinders, sensors, linear sliding rails and customized brackets without additional conversion adapters, improving equipment assembly efficiency.

The modular hole position design is highly adaptable, compatible with various non-standard automated equipment configurations. Whether for new equipment development and assembly or old production line renovation and upgrading, this base plate can perfectly match structural requirements and minimize secondary modification workload.

Application Scenarios: Where This Base Plate Performs Best

Engineered for high-precision and repeatable industrial automation operation, our CNC Base Plate for Automated Equipment delivers stable and excellent performance in multiple core scenarios.

In automated tooling and fixtures, it provides ultra-flat and rigid reference surfaces to ensure consistent positioning and clamping accuracy of workpieces. In robot structural modules, the lightweight and high-precision design ensures accurate joint assembly while avoiding excessive equipment load.

For vision inspection equipment, the 0.05mm ultra-low flatness tolerance maintains long-term alignment accuracy of cameras and sensors, guaranteeing stable inspection data. In assembly line drive brackets, the integrated rigid structure and corrosion-resistant surface withstand long-cycle continuous production without dimensional deviation or structural failure.

Quality Control & B2B Supply Advantages

We strictly implement ISO 9001 quality management system in all production links. Each batch of base plates adopts professional tooling positioning and full 3D coordinate precision inspection, and official dimensional inspection reports can be provided with goods to support customers’ incoming quality verification.

Our team features strong independent R&D capabilities, with R&D personnel accounting for 36% of total employees and 8% of annual revenue invested in technical iteration and process optimization. We achieve precise and stable process control for every customized and bulk order.

Compared with European and American suppliers, our localized Chinese manufacturing supply chain helps global B-end customers reduce comprehensive procurement costs by 30%–40%, with zero compromise on dimensional accuracy, surface quality and structural stability. We support full-process customized production based on customers’ 2D/3D drawings and provide professional DFM optimization feedback before mass production.

Frequently Asked Questions

Q1: Do you support full customization of base plate dimensions and hole positions?

A1: Yes, full non-standard customization is available. We can adjust the overall outline size, add or remove threaded holes, modify hole spacing, and customize natural/black/hard anodizing finishes according to your engineering drawings.

Q2: Is the anodized surface suitable for long-term use in cutting fluid and humid workshop environments?

A2: Absolutely. The tightly bonded anodized film resists peeling, oxidation and corrosion, adapting to conventional workshop humidity, oil mist and cutting fluid erosion. Hard anodizing upgrade is available for higher wear-resistant scenarios.

Q3: What precision can be guaranteed for mass production orders?

A3: The standard mounting hole tolerance is ±0.01mm and datum flatness is 0.05mm. We adopt unified tooling positioning and full 3D testing for mass production to ensure consistent batch quality, with test reports provided on request.

Q4: Can the material be upgraded to 7075 aluminum for higher strength demands?

A4: Yes. We can replace 7075 high-strength aluminum alloy for equipment with higher load-bearing and anti-deformation requirements. Our engineering team will recommend the most suitable material solution based on your actual working conditions.

Q5: What drawing formats are acceptable for custom production?

A5: We support STEP, IGES, DWG, PDF and other mainstream file formats. We can also assist with professional drawing sorting and design optimization if you only have rough dimensions or sketches.

Q6: Can I get prototype samples before bulk ordering?

A6: Yes. We support prototype sampling and first-article inspection (FAI) services, providing complete dimensional test reports for your confirmation to eliminate dimensional risks for mass production.
