Precision Metal Components for Industrial Automation — CNC Machined Cylinder Mounting Supports with ±0.01mm Accuracy

Wuxi Kaihan Technology Co., Ltd. specializes in manufacturing high-stability Precision Metal Components tailored for harsh industrial automation operating conditions. This CNC-machined cylinder mounting support is crafted from premium Q235-A carbon steel and finished with durable white powder coating. Adopting professional 3-axis and 4-axis CNC milling, the product maintains a strict key hole tolerance of ±0.01mm, delivering outstanding dimensional accuracy and assembly consistency.

With standard base plate dimensions of 111×84mm, a Φ22.8mm central shaft hole and four Φ10.5mm mounting holes, the finished component weighs 1.715kg, providing solid load-bearing and fixed support for pneumatic equipment and automated systems. Leveraging 15 years of precision machining experience and 22 technical patents, our factory supplies reliable Precision Metal Component for global automation clients, helping buyers achieve 30%–40% cost savings compared with Western brand suppliers with identical quality standards.

Product Characteristics: Built for Stability and Longevity

Constructed from high-rigidity Q235-A carbon steel, this cylinder mounting support features excellent mechanical strength, effectively resisting axial and lateral loads generated by industrial cylinders. It remains free from deformation, cracking and structural fatigue even under long-term repeated mechanical stress, ensuring stable equipment operation.

The white powder coating is engineered for industrial durability rather than simple aesthetics. Forming a tightly adhered protective film on the steel surface, it delivers reliable resistance against workshop corrosion, ambient humidity and minor physical impact, fully adapting to long-cycle continuous operation in factory environments.

Adopting integrated three-axis and four-axis CNC milling technology, the component achieves a smooth, burr-free surface. It can be directly installed and put into use without secondary grinding or surface finishing, greatly improving on-site assembly efficiency for automated production lines.

Technical Specifications

Precision Machining and Quality Control

We implement a full-process standardized quality control system for every batch of Precision Metal Components. The four-point symmetrical mounting base structure is scientifically designed to eliminate assembly deviation. The key hole position tolerance is strictly controlled at ±0.01mm, ensuring zero error alignment with cylinder mounting flanges for each installation.

Our production and quality management strictly comply with ISO 9001:2005 certification standards. R&D personnel account for 36% of the total staff, with annual R&D investment reaching 8% of revenue. We embed precision engineering standards into every machining procedure, realizing whole-process quality control instead of relying solely on final finished product inspection.

The lean production system effectively reduces batch machining errors from raw material cutting to final surface treatment. It guarantees consistent dimensional accuracy and surface quality for mass orders, which is critical for automated assembly line supporting equipment with high requirements for part consistency.

Application Scenarios in Industrial Automation

This CNC-machined cylinder mounting support acts as a stable fixed connection interface between industrial cylinders and equipment frames. It effectively absorbs vibration generated by high-frequency reciprocating operation and avoids positioning offset of pneumatic components during long-term cyclic movement.

Widely applicable to conveyor automation systems, robot tooling fixtures, pneumatic pressing equipment and linear actuator assemblies, the four-point mounting structure evenly disperses mechanical load, eliminates local stress concentration and extends the overall service life of pneumatic systems. The standard Φ22.8mm central hole fits most small and medium-sized industrial cylinders, with customized hole sizes available for non-standard equipment requirements.

Customization and Supply Flexibility

We support both standard batch supply and personalized non-standard customization. On the basis of standard specifications, we can customize base plate overall dimensions, central shaft hole aperture and mounting hole layouts according to customer drawings. Alternative surface treatments such as galvanizing and electrophoresis coating are also available to adapt to different working environments.

Equipped with independent R&D, design and full-process manufacturing capabilities, our technical team (with senior engineers having top industrial manufacturing experience) provides professional DFM feedback and rapid sample confirmation for customized projects.

Compared with European and American suppliers, our localized manufacturing mode helps global B-end buyers cut procurement costs by 30%–40%. All customized and standard Precision Metal Components fully comply with international industrial precision standards, with stable and reliable comprehensive performance.

Frequently Asked Questions

Q1: What types of industrial cylinders does this mounting support fit?

A1: The standard Φ22.8mm central hole matches most mainstream small and medium-sized industrial cylinders. We provide full custom sizing for non-standard cylinder specifications to meet your unique assembly needs.

Q2: Is the powder coating finish suitable for humid and corrosive workshop conditions?

A2: Yes. The white powder coating features strong adhesion and excellent resistance to rust, corrosion and minor impact. For harsh working environments, we can upgrade to galvanizing or electrophoresis coating for enhanced protection.

Q3: What precision tolerance can be guaranteed for mounting holes?

A3: All key mounting hole positions are strictly controlled within ±0.01mm via 3-axis and 4-axis CNC precision milling. Every product undergoes full dimensional inspection before shipment to ensure assembly accuracy.

Q4: Do you support custom base plate sizes and structures?

A4: Customization is fully supported. We can adjust base plate dimensions, hole layouts and structural features according to your 2D/3D drawings, with professional technical evaluation provided before production.

Q5: Is this component applicable for high-frequency automated equipment?

A5: Absolutely. The high-rigidity Q235-A steel material resists deformation and structural fatigue under repeated loads, perfectly adapting to high-cycle operation of automated pneumatic systems and assembly lines.

Q6: What are your MOQ and delivery terms?

A6: We support flexible orders including sample prototyping and mass production. MOQ and lead time vary by specifications and order volume. Contact us for targeted quotation and delivery schedule.

Contact Us

If you are sourcing high-precision, cost-effective Precision Metal Components for industrial automation and pneumatic system projects, feel free to reach out to our professional engineering team. We provide customized solutions, technical consultation and full after-sales support for global industrial clients. Send your drawings and requirements via email: service@kaihancnc.com for a fast formal quote.
